| Picture : |
|
| Authentication : | In Production RoHS REACH |
| Product Type： | Metal Film Chip Resistor |
| Series | ELR Series |
| Size： | 1020 |
| Resistance Value： | 0.15Ω(150mR) |
| Resistance Tolerance： | ±1% |
| TCR(ppm)： | ±100PPM |
| Resistance Power： | 2W |
| Packing Type: | |
| MOQ: | 12000.0 |
| Minimum Package Quantity: | 4000.0 |
| Product Longevity Program: | 10 Years |
| Part Number | Category | Size | Resistance Value | Resistance Tolerance | TCR(ppm) | Resistance Power | Series | Operation |
|---|---|---|---|---|---|---|---|---|
| EWLR00FSR150EDW | Metal Film Chip Resistor | 1020 | 0.15Ω(150mR) | ±1% | ±100PPM | 2W | ELR Series | |
| ELR25FSR680DDS | Metal Film Chip Resistor | 2512 | 0.68Ω(680mR) | ±1% | ±50PPM | 2W | ELR Series | |
| ELR08FV2R80DES | Metal Film Chip Resistor | 0805 | 2.8R | ±1% | ±50PPM | 1/4W | ELR Series | |
| ELR08FU3R40DES | Metal Film Chip Resistor | 0805 | 3.4R | ±1% | ±50PPM | 1/2W（0.5W) | ELR Series | |
| ELR16FT1R80DES | Metal Film Chip Resistor | 1206 | 1.8Ω | ±1% | ±50PPM | 1W | ELR Series | |
| ELR16FT2R80DES | Metal Film Chip Resistor | 1206 | 2.8R | ±1% | ±50PPM | 1W | ELR Series | |
| ELR06FG5R90DES | Metal Film Chip Resistor | 0603 | 5.9R | ±1% | ±50PPM | 2/5W | ELR Series | |
| ELR16FT3R40DES | Metal Film Chip Resistor | 1206 | 3.4R | ±1% | ±50PPM | 1W | ELR Series | |
| ELR06FG1R80DES | Metal Film Chip Resistor | 0603 | 1.8Ω | ±1% | ±50PPM | 2/5W | ELR Series | |
| ELR06FG2R80DES | Metal Film Chip Resistor | 0603 | 2.8R | ±1% | ±50PPM | 2/5W | ELR Series |
